UPS Eaton 9SX 20KVA 9SX20KPM 20000W 20KVA

Input - Rated input voltage 1 phase 220/230/240V; 3 phase 380/400/415V - Input voltage range 160V~300V full load; 100~160V liner derating - Rated input frequency 50Hz/60Hz - Input frequency range 40 Hz– 70 Hz - Input frequency phase lock range 50Hz system:45 Hz– 55 Hz; 60Hz system:54 Hz – 66 Hz - System compatibility TN-S / IT - Input power factor (PF) >0.995 both 1 phase and 3 phases - THDi 3% linear load; 5% non-linear load Physical dimension Dimension (H*W*D) 129mm*438mm*589mm Net weight (Kg) 23.7 Environment - Operation temperature 0°C ~ 50 °C (0~40 no derating 40°C~ 50°C derating to 50%) - Storage temperature -25°C~60°C - Relative humidity 0 ~ 95% - Operating altitude 0~4000m (0~1000m no derating, 1000m~4000m the load derating 1 % every up 100m) - Noise level <55dB - Warranty 5 years EBM Dimension (H*W*D) 129mm*438*589mm Net weight (Kg) 124.2 MBP (maintenance bypass) Dimension (H*W*D) 129mm*438*489mm Net weight (Kg) 21.5
