UPS APC SRV1KIL adalah unit UPS (Uninterruptible Power Supply) On-Line dari seri APC Easy UPS, dirancang khusus untuk memenuhi kebutuhan Extended Runtime (waktu backup diperpanjang). Model ini adalah unit dasar (modul UPS) yang harus dihubungkan ke paket baterai eksternal (dijual terpisah) untuk mencapai waktu backup yang panjang.
UPS Easy APC fase tunggal ini dirancang untuk profesional TI atau administrator jaringan untuk menjaga waktu aktif dan kontinuitas bisnis. UPS menara on-line konversi ganda 1000VA ini menyediakan daya gelombang sinus murni dan waktu kerja yang lebih lama untuk mendukung perangkat elektronik penting selama gangguan daya. SRV dilengkapi dengan input IEC 320 C14 dan 3 stopkontak IEC 320 C13. UPS On-Line ini memiliki slot kartu pintar untuk Kartu Manajemen Jaringan opsional (AP9544, SRVSMB001, VGL9601l) yang memungkinkan pemantauan dan manajemen UPS berbasis jaringan. UPS ini dapat terhubung ke EcoStruxure IT atau platform manajemen terpusat pihak ketiga. Bypass otomatis dan manual bawaan memberikan daya tanpa hambatan ke beban bahkan jika terjadi kesalahan atau error internal yang terdeteksi pada UPS. UPS dan baterai timbal-asam bawaan bergaransi 2 tahun. Ideal untuk pusat data kecil, fasilitas manufaktur, ruang komputer, perangkat penyimpanan jaringan, telekomunikasi, dan TI layanan kesehatan.
| Presentation |
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
|
| Lead time |
Usually in Stock
|
| Run time for load W Min-max: 80-800 W |
23min 43s |
| Max. Capacity Used | 100 % |
| Main Input Voltage |
230 V AC 1 phase
|
| Product or component type |
Uninterruptible power supply (UPS)
|
| Other Input Voltage | 220 V 240 V |
| Output voltage |
230 V AC 1 phase
|
| Other Output Voltage | 220 V 240 V |
| Rated power in W | 800 W |
| Rated power in VA | 1000 VA |
| Input Connection Type |
IEC 60320 C14
|
| Output connection type |
3 IEC 60320 C13
|
| Cable length | 1.50 m |
| Number of cables | 1 |
| Provided equipment |
1 IEC 60320 C13 to Schuko power cable
1 IEC 60320 C13 to C14 power cable 1 USB cable 1 RS-232 configuration cable 1 battery cable user manual |
| Range of product |
Easy UPS On-Line
|
| Battery type |
Lead-acid external included
|
| UPS connectivity |
Serial port
USB port Available expansion slot |
| Mounting mode | Tower |
| Run Time | |
| Efficiency | |
| Battery type |
Lead-acid battery
|
| Battery voltage | 36 V |
| Extended runtime | 1 |
| Number of battery filled slots | 0 |
| Number of battery free slots | 0 |
| Battery recharge time | 4.5 h |
| Battery life | 3…5 year(s) |
| Battery charger power | 175 W rated |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Redundant | No |
| Colour |
Black (RAL 7010)
|
| Height | 238 mm |
| Width | 290 mm |
| Depth | 400 mm |
| Net weight | 24 kg |
| Mounting location | Front |
| Mounting preference |
No preference
|
| Mounting mode |
Not rack-mountable
|
| USB compatible | No |
| Mounting position | Vertical |
| Input voltage limits |
110...285 V half load
160...280 V full load |
| Network frequency |
40...70 Hz auto sensing
|
| Maximum configurable power in VA | 1000 VA |
| Maximum configurable power in W | 800 W |
| Output frequency |
50/60 Hz +/- 3 Hz sync to mains
|
| Harmonic distortion | 3 % |
| UPS type |
Double conversion online
|
| Wave type | Sine wave |
| Efficiency |
88 % (full load)
|
| Additional information |
Configurable for 220 : 230 or 240 nominal output voltage
|
| Bypass type |
Internal bypass (automatic and manual)
|
| Crest factor | 3 : 1 |
| Product certifications | CE UKCA EAC TISI |
| Standards |
EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
| Ambient air temperature for operation | 0…40 °C |
| Relative humidity |
0…95 % non-condensing
|
| Operating altitude | 0...3000 m |
| Ambient air temperature for storage | -20…50 °C |
| Storage Relative Humidity |
0…95 % non-condensing
|
| Storage altitude | 0…15000 m |
| Acoustic level | 50 dBA |
| Heat dissipation | 372 Btu/h |
| IP degree of protection | IP20 |
| Alarm |
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
|
| Free slots | 1 |
| Control panel |
Multifunction LCD status and control console
|
| Surge energy rate | 600 J |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 2 |
| Package 1 Height | 35.5 cm |
| Package 1 Width | 47 cm |
| Package 1 Length | 52.5 cm |
| Package 1 Weight | 26.7 kg |
| Warranty |
2 years repair or replace
|
