Eaton 9PX UPS 3:1 HotSwap Netpack, 11 kVA, 10 kW, Input: Hardwired, Outputs: (4) C19, Hardwired, Rack/tower, 6U, Network card included
Produk ini adalah solusi Uninterruptible Power Supply (UPS) online premium yang dirancang untuk lingkungan TI kritis yang membutuhkan input daya tiga fase (3-Phase) namun menghasilkan output daya fase tunggal (1-Phase).
Paket ini menawarkan performa tinggi, efisiensi energi terdepan, dan kemampuan manajemen jaringan yang canggih dalam konfigurasi rak yang ringkas.
| Topology |
On-line double conversion with PFC (Power Factor Correction) system
|
| Configuration | Rack/Tower |
| Part Number | 9PX11KiRT31 |
| Rating (VA/Watts) | 11000/10000 |
| Dimensions (H x W x D, mm) |
440 x 260 x 700
|
| Weight (kg) | 88 |
| Warranty |
3 Years / 2 years warranty
|
| Rail Kit Included | Yes |
| Electrical Input | |
| Connection |
Hardwired – see manual for terminal block layout
|
| Input Voltage Range |
305V-480V without derating (up to 175V-480V with derating)
|
| Nominal Voltage | 380/400/415V |
| Frequency |
50/60 Hz autoselection
|
| Frequency Range | 40-70 Hz |
| Short Circuit Current | 150 A |
| THDI | <5% |
| Electrical Output | |
| Voltages |
200/208/220/230/240/250V +/– 1%
|
| Voltage THD | < 2% |
| Output Receptacles |
Hardwired – see manual for terminal block layout
|
| Overload Capacity |
102–110% : 120s, 110–125%: 60s, 125–150%: 10s, >150%: 900ms
|
| Efficiency (Normal Mode) |
Up to 95% in Online mode, 98% in Hi-Efficiency mode
|
| Output Frequency |
50/60 Hz autoselect, frequency converter as standard
|
| Battery Management |
ABM® and Temperature compensated charging method (user selectable), automatic battery test, deep discharge protection, automatic recognition of external battery units.
|
| Extended Battery Capability | EBM (3U) |
| Communications | |
| User Interface |
Multilingual graphical LCD display
|
| Communication Ports |
1 Network management card, 1 USB port, 1 RS232 serial port (USB and RS232 ports cannot be used simultaneously), 4 dry contacts (DB9), 1 mini terminal block for remote On/Off and 1 for remote power Off, 1 DB15 for parallel operation
|
| Environmental & Standards | |
| Audible Noise | <50dB |
| Operating Temperature |
0 to 40°C continuous
|
| Safety markings |
IEC/EN 62040-1
|
| EMC Markings |
IEC/EN 62040 -2 , IEC/EN 62040-3 (Performance)
|
| Approvals |
CE, CB report (TUV)
|
| Vendor | AMS Network |
|---|---|
| Type | UPS |
| Sku | 4 |
| Weight | 90.0 kg |
